Wireline Units

Reel Power ME single drum wireline unit and slick line unit can be deployed for running and retrieving down-hole tools, performing light duty wireline and fishing operations..



Reel Power ME single drum wireline unit and slick line unit can be deployed for running and retrieving down-hole tools, performing light duty wireline and fishing operations. Compact, lightweight, low maintenance wireline units are fully functional housed in a robust frame with a control console. Integral forklift pockets and single point lift is provided for ease of crane handling. This ergonomically designed unit with all controls at a comfortable height and an unrestricted view of the action on the rig floor for the operator.



More Information
Product Brochure View FileWireline Units
Model/Option

Options:

Rig powered hydraulic and electric hydraulic drive systems available
Automatic levelwind
Hinged safety glass on front of machine for easy access during routine maintenance
Urethane wiper system atop the machine to minimize debris entering the traverse assembly as wireline is deployed and returned to the drum
Weight indicators, complete with load cell and 50 ft. hose
Carbon or stainless steel wireline
Disc or drum brakes available
Hay pulley and turning sheaves

  • Controls:  Dual direction control and brake control mounted on stainless steel console.  Pressure gauge provided. Console mounted at a comfortable height for the operator.
  • Wireline Drum: Chain or direct driven seal welded steel drum.
  • Drive: Open loop and closed loop hydraulic drives system.  Transmission available as application requires.
  • Brake:  High performance dual drum or discbrake to provide backtension and avoid overrun.
  • Levelwind:  Manual and automatic level wind to guide the material evenly across the face of the drum.
  • Depth Counter: Depth measuring counter (7” wheel) mounted to the levelwind.  Depth counter may be provide in English or Metric units.
  • Guarding: Guards provided for personnel protection at pinch points and rotatinng components. Access panels easily removed for routine maintenance.
  • Transporting: Single lift eyes on frame and forklift pockets for easily transporting the unit.
  • Land and Offshore Drilling Rigs
  • Surveys
  • Running Downhole Tools
  • Performing Light Duty Wireline Operations
  • Fishing Operations
